Stainless Steel 304L Pipe
Standards :ASME B36.10, ASME B36.19
Specifications :ASTM A312, ASME A213, ASTM A269
Size :1/2' – 48'
Thickness : 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS
Type :Seamless / Welded / Fabricated
ASTM A312 Stainless Steel 304L Pipe Grade Specifications
|
STANDARD
|
UNS
|
WERKSTOFF NR.
|
AFNOR
|
EN
|
JIS
|
BS
|
GOST
|
|
SS 304L
|
S30403
|
1.4306/1.4307
|
Z3CN18‐10
|
X5CrNi18-10
|
SUS 304L
|
304S11
|
03Х18Н11
|
Stainless Steel 304L Pipe Chemical Composition
|
Grade
|
P
|
Ni
|
Si
|
N
|
C
|
S
|
Mn
|
Cr
|
Mo
|
|
304L
|
min.
|
-
|
8.0
|
-
|
-
|
-
|
-
|
-
|
18.0
|
-
|
|
max.
|
0.045
|
10.5
|
0.75
|
0.10
|
0.08
|
0.030
|
2.0
|
20.0
|
Stainless Steel 304L Pipe Fittings Mechanical properties
|
Grade
|
Tensile Strength (MPa) min
|
Elongation (% in 50mm) min
|
Yield Strength 0.2% Proof (MPa) min
|
Hardness
|
|
Rockwell B (HR B) max
|
Brinell (HB) max
|
|
304L
|
485
|
40
|
170
|
92
|
201
|
