Stainless steel UNS S31609 plate, UNS S31609 SS plate, Stainless steel 316H plate, SS 316H sheet, 316H Stainless steel sheet, 1.4919 steel plate, ASTM A240 UNS S31609 Stainless steel Plate and sheet
Relevant furnace temperature and protective atmosphere requirements should be followed when 316H stainless steel plate was processed to ensure the uniformity of alloy composition. During the rolling process, the rolling temperature and deformation temperature are controlled to obtain the required plate size and properties. Temperatures that are too high may cause grain growth and material softening, while temperatures that are too low may cause rolling difficulties and surface quality problems.
Stainless steel UNS S31609 plate Chemical Composition，%
|
Grade
|
C
|
Si≤
|
Mn≤
|
P≤
|
S≤
|
Cr
|
Mo
|
Ni
|
|
316H
|
0.04--0.10
|
0.75
|
2.00
|
0.045
|
0.030
|
16.00--18.00
|
2.00--3.00
|
10.00--14.00
|
Annealing is an important step in the production of UNS S31609 316H steel plates, used to eliminate stress, improve the structure and improve the mechanical properties of the material. Annealing temperature and time should be selected on a case-by-case basis to achieve the desired material properties.
During the production process, proper cooling control of SS 316H steel plates is required. Control cooling rate and pattern to achieve desired texture and performance. Rapid cooling results in higher strength, while slow cooling improves the material's toughness.
Stainless steel UNS S31609 plate Specification
| Type |
Plate, Sheet |
| Standard |
ASTM,AISI, AMS,MLS,EN,JIS,DIN,GOST |
| Thickness |
1.2-100mm |
| Width |
1000-1500mm |
| Length |
1000-6000mm |
| Surface |
2B, No.3, No.4, HL, BA, 8K |
| Manufacturing process |
Hot rolled, cold rolled |
| Packing |
Bubble bag and plywood pallet or according to the customers' requirements. The inner size of container is below: 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM |
| Delivery time |
10-100 days depending on quantity |
| Payment terms |
T/T |
| Shipment |
FOB Tianjin/Shanghai, CIF, CFR, etc |
| Application |
Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc |
| Remarks |
Other materials and drawings are available. |
| Welcome to contact us ;Zhengzhou Huitong Pipe Fittings Co.,Ltd (32 years manufacturing experience) |
