WERKSTOFF NR. 2.4668 Welded Tube & AMS 5589 Tubing supplier and stockist in China
Alloy 718 Nickel Tube is an age-hardenable nickel-chromium-iron alloy that also contains significant amounts of niobium, molybdenum, titanium and aluminum. Inconel 718 pipe combines good corrosion resistance with extremely high strength. Inconel WERKSTOFF NR.2.4668 Tubing is designed for applications requiring very high yield strength, high tensile strength, and good creep rupture properties. Astm B163 Alloy 718 seamless tubing for condensers and heat exchangers. Alloy 718 heat exchanger tubes cover outside diameter and average wall to minimum wall thickness as required.
A unique feature of this particular Gamma Prime strengthened alloy is its superior mechanical strength between -423 °F to 1300 °F. The production of Alloy 718 Condenser and Heat-Exchanger Tubes is in accordance with specification ASTM B163. In several industries, the application of heat exchangers includes the cooling as well as heating of large scale manufacturing systems. In such systems, there is an exhaustion of steam or some waste of energy. The Inconel 718 AMS 5589 Tubing, a part of these heat exchangers, is useful in the recovery of heat. The heat accumulated by these tubes could be applied to another system. Typically, the supplication of heat via other sources is not only expensive, but it is also harmful to the environment. Thus, the installation of ASME SB 163 UNS N07718 tubes proves to be a cost-efficient solution.
The thermodynamic relationships in all large scale processing industries such as Wastewater treatment, nuclear power, Petroleum refining, Refrigeration in addition to the Wine and beer making industry varies. The temperature, flow, viscosity, density, pressure, phase, chemistry etc of each product in these industries is different. For instance, in a wastewater treatment plant, a double Inconel 718 Tube is a common sight. As heat exchangers, the ASTM B163 UNS N07718 play a vital role within anaerobic digesters. Inconel 718 pipe maintains optimised temperatures required for the growth of microbes, which in turn – eliminates pollutants. Using an Inconel 718 Seamless Tube in such applications ensures superior performance. Since Inconel 718 pipe is amongst the most resilient ones, even under highly stressful conditions, like oxidation, the Inconel 718 Tubing will exhibit resistance up to a temperature as high as 1800 °F. Following specification ASTM B163, the Inconel 718 Welded Tube is tested for conformance of its mechanical properties, including tensile and yield strength, Rockwell hardness and elongation.
| ASTM B163 Alloy 718 Tubing Standards | ASTM B163/ ASME SB163, ASTM B516/ ASME SB516 |
|---|---|
| ASTM B163 Alloy 718 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| ASTM B163 Alloy 718 Welded Tube Size | 6.35 mm OD To 152 mm OD |
| ASTM B516 inconel 718 Tubing Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Inconel WERKSTOFF NR. 2.4668 Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Inconel UNS N07718 Tubing Length | Single Random, Double Random, Standard & Cut length Tube |
| Inconel WERKSTOFF NR. 2.4668 Tubing Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | ‘U’ bent, Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Etc |
| Types of 718 Alloy Tubing | Seamless, ERW, EFW, Welded, Fabricated Tube / Tubing |
| 718 Alloy Tube End | Plain End, Beveled End, Treaded Tube |
| Marking | All ASTM B163 inconel 718 Tubing are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application & uses of inconel 718 Tube | Oil Tube, Gas Tube, Fluid Tube, Boiler Tube, Heat exchanger Tube, |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialize in | ASTM B163 inconel 718 Capillary Tube & Other Odd Size inconel NCF 718 Heat Exchanger & Condenser Tube |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Manufacturers of inconel 718 Tube |
|
| We can also cut, thread, and groove inconel NCF 718 Tube to meet your specifications. inconel 718 Tube Dimension ANSI/ ASME B36.10, B36.19, B2.1 | |
