ASME B16.5 Alloy Steel Flange for petroleum

Nilo Alloy 36, W.Nr 1.3912, Invar 36® is a nickel-iron, low controlled expansion alloy that contains 36% nickel and possesses a rate of thermal expansion approximately one-tenth that of carbon steel.
Invar 36 Specifications: UNS K93600, W.Nr 1.3912

Common Trade Names: Nickel Alloy 36, Invar 36®, Nilo 6®, Pernifer 6®
Invar 36® is a nickel-iron, low expansion alloy that contains 36% nickel, Invar 36 has a low coefficient of expansion from cryogenic temperatures to about +500°F (260°C).
Invar 36 Tube OD:0.2-6mm, WT: 0.02-2mm

Nilo / Alloy K W.Nr.: 1.3981
UNS: K94610 ASTM F15
Fixed-expansion glass-encapsulated iron-nickel-cobalt alloys, Kovar alloys, have a linear thermal expansion coefficient similar to that of hard glass within a certain temperature range
For mating sealing with hard glass

A335 P9 seamless pipe is a type of chrome molybdenum pipe listed in ASTM A335 (ASME S/A335, Chrome-Moly), which has become the standard in the power generation industry and petrochemical industry, not only because of its tensile strength, corrosion resistance resistance and high temperature strength, but also because of its cost-effectiveness. Chromium molybdenum tubes are popular in P grades P5, P9, P11, P22, P91 and P92. The P11, P22 and P91 grades are most commonly used in the powder industry and petrochemical plants, while the P5 and P9 grades are often used in oil refineries.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.66

SA182 F11 plate flanges are used to seal the ends of pipes, valves or other connections. It is also called flat flange, flat flange, etc. It is a flat circular disc that is welded to the end of a pipe and allows it to be bolted to another pipe.

Chromium molybdenum has a better strength-to-weight ratio than steel, which enables designers to use thinner walled tubing or smaller diameter tubing to reduce overall weight.

ASTM A182 Alloy Steel Pipe Fittings are very easy to install and have a low hub due to the pipe going into the fitting before welding.

Low alloy steels contain trace amounts of alloying agents such as niobium, nitrogen, vanadium, copper, nickel, chromium, titanium, calcium, molybdenum, rare earth elements or zirconium.

This is used in fabrication of tubes, boilers and super heaters. On many other applications, this is used and is available in various other sizes and shapes.

Alloy steel seamless pipes are used in applications that require high precision for ease of installation and accuracy of operation and application. Different types are used for different mechanical benefits. Most applications require a lot of welding, so welding alloy steel pipes is good for them. Some are low in strength but high in corrosion resistance, and some are also high in strength. We offer high strength low alloy steel pipes in various grades and sizes.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.63

ASTM A335 P22 Seamless Pipe can be used in forming operations without cracking. This tube can be bent, forged, flanged and fusion welded. It also has very high tensile strength, corrosion resistance and yield strength.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.41

After hot working, forgings should be cooled to a temperature below 1000¡ãF (538¡ãC) prior to heat treatment in accordance with ASTM A182. Low alloy steels and ferritic and martensitic stainless steels shall be heat treated in accordance with ASTM A182.

These well-controlled advantages of Astm a182 alloy steel F9 round bars are evident in automated operations where even modest changes in flow temperature can significantly increase the incidence of scrap.

Alloy steel is steel that is alloyed with a variety of elements in total amounts between 1.0% and 50% by weight to improve its mechanical properties. Alloy steels are broken down into two groups: low alloy steels and high alloy steels. The difference between the two is disputed. Smith and Hashemi define the difference at 4.0%, while Degarmo, et al., define it at 8.0%.[1][2] Most commonly, the phrase “alloy steel” refers to low-alloy steels.

HASTELLOY C-276 alloy (UNS N10276) was the first wrought, nickel-chromiummolybdenum material to alleviate concerns over welding (by virtue of extremely low carbon
and silicon contents).

Chrome molybdenum grades P11, P22, P91 and P92 are used in the power industry. Chromium molybdenum grades P5 and P9 are used in petrochemical refining processes. Chrome molybdenum forged fittings and flanges are available in grades F5, F9, F11, F22, F91, F92. Chrome-molybdenum alloy butt welded pipe fittings are available in WP5, WP9, WP11, WP22, WP91, WP92 grades. F11 and F22 materials comply with NACE-MRO 175.

It is a standard specification defining typical chemical composition, mechanical properties, hardness requirement, preferential heat treatment, product marking, certification and other requirements, suitable for bolting used in pressure vessel service, valves, flanges and fittings. ASTM A193 defines both SI (Metric) and inch-pound units.

ASTM A182 Grade F2 is an alloy steel used for preliminary forming into forged products. The properties cited apply to the annealing conditions. F2 is the ASTM designation for the material. K12122 is the UNS number.

B7 and B7M shall be heat treated by quenching in a liquid medium and tempering. For B7M fasteners, the final heat treatment, which may be the tempering operation if conducted at 1150 ¡ãF [620 ¡ãC] minimum, shall be done after all machining and forming operations, including thread rolling and any type of cutting.

Blind flanges have the face thickness of a flange, a matching face type, and similar bolting pattern.

The Alloy Steel Weld Neck Flange has a welded neck onto it that holds larger pipes in place for easy welding and installation.

Through tests and production tests, molybdenum in A335 is currently the most effective additive for improving high temperature creep strength. Molybdenum-added seamless steel pipes also show enhanced corrosion resistance and inhibition of pitting corrosion.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.19
Material Alloy Steel ASTM A333 Grade 3, Grade 6,Grade 8,Grade 9
ASTM A335 P5,P9,P11,P12,P22,P91,P95

Alloy 20 (Alloy 20) is an iron-based austenitic alloy developed to resist sulfuric acid corrosion. It has excellent resistance to sulfuric acid corrosion; it has strong resistance to phosphoric acid, nitric acid and chloride environments, chloride stress corrosion, pitting corrosion and crack corrosion. Therefore, alloy 20 has the name of anti-corrosion alloy; it has a wide range of applications: such as: chemical, food, medicine, power production and plastics industries will use it. For resistance to pitting corrosion and chloride corrosion, stress corrosion cracking problems, etc., alloy 20 is often used.

A335 pipe is highly resistant to rupture at high temperature and pressure. Chromium molybdenum tubes with resistance to hydrogen cracking and sulfide stress corrosion cracking are superior to carbon tubes.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.60

The wider range of flanges are being offered like ASTM A182 F9 slip flange, F9 alloy welded steel socket flange, alloy steel F9 orifice flange, A182 F9 threaded and screwed flange etc. Imperative for the uniqueness of Alloy Steel F9 Socket Weld Flanges is the allotropy of iron-that is, its existence in two crystalline structures.

Alloy Steel F11 Flanges specifications are also mentioned and the face type starts from flat face, raised face, ring type joint and many more.

Each tube of the A335 shall be hydrostatically tested. In addition, each tube shall be inspected using non-destructive testing methods in accordance with prescribed practices.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.21

Chromium and molybdenum are high in A335 pipes. While molybdenum improves overall strength, resistance, elasticity, hardenability and overall quality, molybdenum ensures that the material is more resistant to softening, inhibits grain growth and reduces the chance of embrittlement. It is the only additive that improves the high temperature resistance and also improves the corrosion resistance of the steel.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.19
Material Alloy Steel ASTM A333 Grade 3, Grade 6,Grade 8,Grade 9
ASTM A335 P5,P9,P11,P12,P22,P91,P105

La especificacion ASTM A193 Grado B7 cubre los requisitos para materiales de empernado de acero aleado de alta resistencia para servicio de alta temperatura o alta presion y otras aplicaciones de proposito especial. Es una especificacion estandar que define la composicion quimica tipica, las propiedades mecanicas, los requisitos de dureza, el tratamiento termico preferencial, el marcado del producto, la certificacion y otros requisitos para las conexiones atornilladas utilizadas en el servicio de recipientes a presion, valvulas, bridas y accesorios. ASTM A193 define unidades SI (metricas) y pulgadas-libras.

These flanges are available in different types such as slip flanges, blind flanges, butt weld flanges, socket weld flanges, orifice flanges, eyeglass blind flanges, threaded/threaded flanges, reducer flanges, ring flanges Type joint flange (RTJ), etc.

A335 gr P22 seamless pipe is easy to install as the dimensions are very accurate. It can be used with other a335 gr P22 alloy pipe types and fittings.
Type Seamless Pipe
Seamless Tube
Welded Pipe
Welded Tube
SAW LSAW ERW EFW
Beveled End, Plain End”
Size OD: 1/2″” ~48″”
Thickness: SCH5~SCHXXS
Length :As per your requirement.”
Manufacturing technique Hot rolling /Hot work ,Cold rolling
Producing Standard ASME B36.10 ASME B36.40

A182 threaded flanges are primarily used for utility services such as air and water. It is similar to a Slip-On flange, but the holes are threaded.

These ASTM A182 Grade F5 Flanges gives extraordinary erosion resistance in, for instance, caustic and acidic applications which includes sulphuric and higher chloride environments. A182 Gr F5 Threaded Flanges are mostly used in utility services such as air and water. It is similar to the Slip-On flange, but the bore is threaded. Its greatest advantage is that it can be assembled without welding, explaining its use in low pressure services at ordinary atmospheric temperatures, and in highly explosive areas where welding create a hazard.
