tri clamp susf flanges suppliers hex head self drilling screw nut flange gasket 304 stainless steel

ASME B36.19M is the standard specification for stainless steel pipes, which specifies the dimensions, tolerance, and manufacturing requirements for both welded and seamless pipes.

Flange is the parts which connects two pipe ends, flange connection is defined by the flange, gasket and bolt three are connected as a group of combined sealing structure of the detachable connection. The gasket is added between the two flanges and then fastened by bolts. Different pressure flange, thickness is different, and the bolts they use are different, when pump and valve connect with pipe, the parts of the equipment are also made of the corresponding flange shape, also known as flange connection, usually closured bolted connection parts are also known as flanges, such as the connection of ventilation pipe, this kind of parts can be called “flange type part”, but this connection is only part of a device, such as the connection between flange and water pump, it’s not inapposite to call water pump as flange type parts,but relative small valve,it can be called as flange type parts .

Although molybdenum is a good element, excessive use of it may reduce the creep ductility of Gr F11 plate flanges. Graphitization and decomposition of iron carbide may occur when the temperature exceeds 500 degrees Celsius. Chromium has been added to SA A182 F11 alloy steel CL.2 forged pipe flanges to prevent creep ductility reduction and graphitization. In addition, the added chromium also provides oxidation resistance.

It is an austenitic stainless steel alloy with high nickel (24%), chromium (22%), molybdenum (6%), and nitrogen (0.18%) content and is commonly known as superaustenitic stainless steel (alloys such as 254 SMO (UNS?S31254) and 904L (UNS?N08904) also fall under the superaustenitic designation) while 2205 (UNS S32305/ S31803) and 2507 (UNS S32750) are duplex and super duplex stainless steel, respectively.

ANSI B16.5 304 316 317 Stainless Steel Forged Weld Neck Flange
Featuring 304 stainless steel for very good corrosion resistance, this GRAINGER APPROVED weld neck flange can be attached to a system via a circumferential weld at the neck. The welded area can be easily examined by radiography. Matched pipe and flange bore reduces turbulence and erosion inside the pipeline. Flange is excellent for use in your critical applications and is ideal for use with air, water, oil, natural gas, and steam.

Steel flanges provide an easy access for cleaning, inspection or modification. They usually come in round shapes but they can also come in square and rectangular forms. The flanges are joined to each other by bolting and joined to the piping system by welding or threading and are designed to the specific pressure ratings; 150lb, 300lb, 400lb, 600lb, 900lb, 1500lb and 2500lb.

A flange can be a plate for covering or closing the end of a pipe. This is called a blind flange. Thus, flanges are considered to be internal components which are used to support mechanical parts.

RFWN Flange (Raised Face Weld neck Flange) are one of the most commonly used flange in the piping industry. They are easy to recognize with their long tapered hub that is matched to the wall thickness (bore) of the pipe.

A flange is a ring of steel (forged, cut from plate, or rolled) designed to connect sections of pipe, or to join pipe to a pressure vessel, valve, pump or other integral flanged assembly. Flanges are joined to each other by bolts, and to the piping system by welding or threading (or loose when stub ends are used). Stainless steel flange simplified as SS flange, it refers to the flanges that made of stainless steel. Common material standards and Grades are ASTM A182 Grade F304/L and F316/L, with pressure ratings from Class 150, 300, 600 etc and to 2500. It used in more industries than carbon steel as stainless steel has better resistant performances on corrosion environment and always provides with a good appearance.

ASTM A182 F316L Slip On Flange
Featuring 304 stainless steel for very good corrosion resistance, this GRAINGER APPROVED weld neck flange can be attached to a system via a circumferential weld at the neck. The welded area can be easily examined by radiography. Matched pipe and flange bore reduces turbulence and erosion inside the pipeline. Flange is excellent for use in your critical applications and is ideal for use with air, water, oil, natural gas, and steam.

Cold working operations will increase the strength and hardness of these stainless steel 316L eyeglass blind flanges and may make them slightly magnetic. Flanges are usually welded or threaded. Flange joints are made by bolting two flanges together with a gasket between them to provide a seal.

The flange is second most used joining method after selding. Flanges are used when joints need dismantling. It provides flexibility for maintenance. Flange connects the pipe with various equipment and valves. Breakup flanges are added in the pipeline system if regular maintenance in required during plant operation.
A flanged joint is composed of three separate and independent although interrdlated components; the flanges, the gaskets, and the bolting; which are assembled by yet another influence, the fitter. Special controls are required in the selection and application of all there elements to attain a joint, which has acceptable leak tightness.
A flange is a protruded ridge, lip or rim, either external or internal, that serves to increase strength (as the flange of an iron beam such as an I-beam or a T-beam); for easy attachment/transfer of contact force with another object (as the flange on the end of a pipe, steam cylinder, etc., or on the lens mount of a camera); or for stabilizing and guiding the movements of a machine or its parts (as the inside flange of a rail car or tram wheel, which keep the wheels from running off the rails). The term “flange” is also used for a kind of tool used to form flanges.

According to ASME B16.5, the hub of the butt welding flange can be roughly divided into a tapered part and a straight long part. The processing straight length is 6mm, which is precisely matched with the adjacent pipes, which is convenient for welding. Butt weld flanges are drilled to match the inside diameter of the adjacent pipe. The thinner the pipe wall, the larger the hole through the flange. The thicker the wall, the smaller the hole. Because of these matching relationships, there are no restrictions on traffic. Turbulence and erosion are thus eliminated.

stainless steel flange is a kind of general steel material, which is widely used to manufacture equipment and parts with high requirements for comprehensive performance (corrosion resistance, formability). stainless steel is a stainless steel grade produced according to American ASTM standards. stainless steel is the most widely used stainless steel and heat-resistant steel. It is applicable to food production equipment, Xitong chemical equipment, nuclear energy, etc.

SMO 254 Flanges is readily available for applications in the industrial, architectural, and transportation fields.

Type 304 stainless steel is named for its composition, which includes 18% chromium and 8% nickel. This stainless steel has good formability and weldability. Due to its composition, stainless steel 304 flanges are highly corrosion resistant and fairly durable.

ASME B16.47 Series A are available in Classes 150, 300, 400, 600, 900; that of ASME B16.47 Series B are available in Classes 75, 150, 300, 400, 600, 900

Duplex Steel UNS S31254 Slip On Raised Flanges combines moderate mechanical strength (typically over 300 MPa yield strength) and high ductility with excellent corrosion resistance in seawater and a variety of industrial environments.

Cross-contamination can corrode the stainless steel square flange base metal, resulting in discoloration of the finished product. Post-weld annealing is recommended for stainless steel 304 sliding flanges. Additionally, cold working of Oatey stainless steel flanges increases tensile strength and hardness. The flanges show a typical tensile strength of 75,000 psi 515 MPa and a yield strength of 30,000 psi 205 MPa. Ansi B16.5 Uns S30400 butt weld flanges can be conventionally hot worked.

Grade 304 stainless steel is the standard “18/8” stainless steel; it is the most versatile and widely used stainless steel available in a wider range of products, forms and finishes than any other. It has excellent forming and welding characteristics. The balanced austenitic structure of grade 304 enables deep drawing without intermediate annealing, which makes this grade dominant in the manufacture of drawn stainless steel components such as sinks, hollowware, and pans.

Alloy steel flange, that is, the main material is alloy steel flange or end flange connection. It contains alloy steel flanges, called alloy steel flanges. Alloy Steel Flanges, Alloy Flanges are carefully designed using current technology under the visionary guidance of accomplished professionals in the manufacturing sector.

ASTM A182 F304 Flanges
?The?ASTM A182 F304 Flanges?could be cleaned easily with a mild detergent. Despite undergoing repeated cleaning processes, these flanges won¡¯t wear away, an ability it exhibits due it its good wear resistance properties. Moreover, since grade 304 is an alloy that can be easily formed into various shapes, it is easily manufactured into any type of?ASME SA182 F304 Pipe Flange?such as a weld neck flange or an?Inox 304 Slip On Flange.

The flanges may be made from forgings, castings, or plates covering various types and classes of ASME B16.5 and ASME B16.47 (both Series A and Series B). Stainless steel 304/ 304L flanges of ASME B16.5 are available in Classes 150, 300, 400, 600, 900, 1500, 2500.

A lap-joint flange is a two-component assembly, with a stub end that has a lap-joint ring flange placed over it. The stub end is then butt welded to the pipe, and the flange ring can be rotated to align with the mating flange. This type of flange connection is particularly useful for large or hard-to-adjust flanges.

304 stainless steel flanges are considered the most basic stainless steel, also known as grade 18-8, with higher chromium content and lower carbon content. The presence of low carbon content in the alloy limits the formation of carbide deposits during welding while minimizing the susceptibility of 304 stainless steel flanges to intergranular corrosion.

While the chemistry of Stainless Steel 304L Flanges is similar to grade 304, there are some changes done to its chemical composition. The modification in the chemistry of grade 304L improves its properties like weldability.

A182 F316 Slip On Flange
Featuring 304 stainless steel for very good corrosion resistance, this GRAINGER APPROVED weld neck flange can be attached to a system via a circumferential weld at the neck. The welded area can be easily examined by radiography. Matched pipe and flange bore reduces turbulence and erosion inside the pipeline. Flange is excellent for use in your critical applications and is ideal for use with air, water, oil, natural gas, and steam.

Stainless Steel 310s Flanges, combining excellent high temperature properties with good ductility and weldability, is designed for high temperature service. It resists oxidation in continuous service at temperatures up to 1150¡ãC provided reducing sulphur gases are not present. It is also used for intermittent service at temperatures up to 1040¡ãC.

Our supplied 309 Stainless Steel Flanges are hardness test and other mechanical tests of tensile of the area and so on before packaging and transportation to guarantee long lasting service to the customers.

Alloy 309 can be utilized in sulfur containing atmospheres up to 1832°F (1000°C). The alloy is not recommended for use in highly carburizing atmospheres since it exhibits only moderate resistance to carbon absorption. Alloy 309 can be utilized in slightly oxidizing, nitriding, cementing and thermal cycling applications, albeit, the maximum service temperature must be reduced.

Steel flanges provide an easy access for cleaning, inspection or modification. They usually come in round shapes but they can also come in square and rectangular forms. The flanges are joined to each other by bolting and joined to the piping system by welding or threading and are designed to the specific pressure ratings; 150lb, 300lb, 400lb, 600lb, 900lb, 1500lb and 2500lb.

A flange can be a plate for covering or closing the end of a pipe. This is called a blind flange. Thus, flanges are considered to be internal components which are used to support mechanical parts.

The ASTM A182 F51 flanges with hub shall be manufactured by a hot forging process, in which the material shall be forged as close as practicable to the specified shape and size.

A bs 4504 316l plate flange is a flat, circular disk that is welded onto the end of a pipe and allows it to be bolted to another pipe. Typically used in fuel and water pipelines, the two plate flanges will be bolted together with a gasket in between them. The plate flange will have bolt holes all around the perimeter and will be used to create junctions, tees and joints.

A flange is a ring of steel (forged, cut from plate, or rolled) designed to connect sections of pipe, or to join pipe to a pressure vessel, valve, pump or other integral flanged assembly. Flanges are joined to each other by bolts, and to the piping system by welding or threading (or loose when stub ends are used). Stainless steel flange simplified as SS flange, it refers to the flanges that made of stainless steel. Common material standards and Grades are ASTM A182 Grade F304/L and F316/L, with pressure ratings from Class 150, 300, 600 etc and to 2500. It used in more industries than carbon steel as stainless steel has better resistant performances on corrosion environment and always provides with a good appearance.
