ASTM A182 F310 WN SO SW BL Flange, Stainless Steel 310 Flange, SS 310 WN Flange, 310 Stainless Steel SW Flange, 310 WN RF Flange, 310 SO rf Flange, ASTM A182 Stainless Steel Flange supplier
ASTM A182 F310 Stainless steel flange Specification:
Standards: ASTM A182
Dimensions: ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, JIS
Pressure Rating: Class 150#, Class 300#, Class 400#, Class 600#, Class 900#, Class 1500#, Class 2500#, PN 6, PN 10, PN 16, PN 25 and PN 40 etc
Flange Facing: Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Flange Types: Welding Neck Flange, Slip On Flange, Socket Weld Flange, Lap Joint Flange, Threaded Flange, Blind Flange, Orifice Flanges, Plate Flange, Long Welding Neck Flanges, Spectacle blind Flange, Orifice Flange, WNRF Flange, SORF Flange, SWRF Flange, Custom Flange as per Drawing etc.
310 Stainless steel flange Chemical Composition, %
| Grade |
UNS |
C≤ |
Mn |
P≤ |
S≤ |
Si≤ |
Cr |
Mo |
Ni |
| 310 |
S31000 |
0.25 |
2.00 |
0.045 |
0.03 |
1 |
24.0-26.0 |
- |
19.0-22.0 |
UNS S31000 Stainless steel flange Mechanical properties
| Mechanical properties |
Tensile, min, ksi[MPa] |
Yield, min, ksi[MPa] |
Elongation in 2 in.
[50 mm] or 4D,
min, % |
Reduction of
Area, min, % |
| 310 |
75【515】 |
30【205】 |
30 |
50 |
HT PIPE is supplier and manufactuter of ASTM A182 Stainless steel Flanges, we supply a wide range of steel flanges: wn flanges，sw flanges, so flanges, lwn flanges, threaded flanges, blind flanges, etc. If you have inquiry, pls contact us!
