Hastelloy steel plate sheet Coil

Material: Hastelloy B2, B3, X, C22, C2000, C276
Width: 0~2500mm or as per your requirements
Length: 0~12m or as per your requirements
Thickness: 0.3~1200mm or as per your requirements

PRODUCT DESCRIPTION

Hastelloy plates includes the Chromium, Molybdenum, Copper, Iron, and Niobium along with Nickel. HT PIPE is a manufacturer, exporter, and supplier of Hastelloy plates materials as B2, B3, X, C2000, C22, C276. Manufacturer of ASTM B575 Hastelloy B2 plates, Hastelloy B3 sheets, Hastelloy C22 plates, Hastelloy X coils, Hastelloy C276 plates sheets coils Material stockist in China.

Specification For Hastelloy B2, B3, X, C22, C2000, C276 steel plates/sheets/coils:
Thickness: 0.1mm to 12 mm Thk
Sheet/Plate Size: 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Coil Width: 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc.
Coil Length: 2000mm, 2440mm, 3000mm, 5800mm, 6000mm etc.

Hastelloy B2, B3, X, C22, C2000, C276 steel plates/sheets/coils Chemical Composition:

Grade	UNS	Cr	Mo	Fe	C≤	Si≤	Co≤	Mn≤	P≤	S≤
B2	N10665	1.0max	26.0-30.0	2.0max	0.02	0.10	1.0	1.0	0.04	0.03
B3	N10675	1.0-3.0	27.0-32.0	1.0-3.0	0.01	0.10	3.0	3.0	0.03	0.01
X	N06002	20.5-23.0	8.0-10.0	17.0-20.0	0.05-0.15	1.0	0.5-2.5	1.0	0.04	0.03
C22	N06022	20.0-22.5	12.5-14.5	3.0-6.0	0.015	0.08	2.5	0.5	0.02	0.02
C2000	N06200	22.0-24.0	15.0-17.0	3.0max	0.01	0.08	2.0	0.5	0.025	0.01
C276	N10276	14.5-16.5	15.0-17.0	4.0-7.0	0.01	0.08	2.5	1.0	0.04	0.03

Hastelloy B2, B3, X, C22, C2000, C276 steel plates/sheets/coils Mechanical Properties:

Mechanical properties	Tensile, min, ksi[MPa]	Yield, min, ksi[MPa]	Elongation, %(min)
B2	110[760]	51[350]	40
B3	110[760]	51[350]	40
X	100[690]	40[276]	35
C22	100[690]	45[310]	45
C2000	100[690]	45[310]	45
C276	100[690]	41[283]	40
